Stainless Steel Wire

Stainless Steel Wire which we produce is made of high grade 304 316L 310S 309S 321 347 201 409L 410 420 430 2205 2507 Stainless Steel .With various dimensional specifications, these Wire find wide applications in manufacturing and fabricating engineering products. Designed with high precision these products are tested and checked for dimensional accuracy and optimum performance.

Availability:


Inquire

Material Grade

美标牌号 ASTM/ASME Grade	欧标代码 EN Grade	国标统一数字代号 GB Unified Number	Chemical Component %
美标牌号 ASTM/ASME Grade	欧标代码 EN Grade	国标统一数字代号 GB Unified Number	C	Cr	Ni	Mn	P	S	Mo	Si	Cu	N	Other
201	1.4372	1Cr17Mn6Ni5N	≤0.15	16.00-18.00	3.50-5.50	5.50－7.50	≤0.060	≤0.030	-	≤1.00	-	≤0.25	-
202	1.4373	1Cr18Mn8Ni5N	≤0.15	17.00-19.00	4.00-6.00	7.50-10.00	≤0.060	≤0.030		≤1.00	-	≤0.25	－
301	1.4310	1Cr17Ni7	≤0.15	16.00-18.00	6.00-8.00	≤2.00	≤0.045	≤0.030	-	≤1.00	-	0.1	-
302	1.4325	1Cr18Ni9	≤0.15	17.00-19.00	8.00-10.00	≤2.00	≤0.035	≤0.030	-	≤1.00	-	-	-
303	1.4305	Y1Cr18Ni9	≤0.15	17.00-19.00	8.00-10.00	≤2.00	≤0.20	≥0.15	-	≤1.00	-	-	-
304	1.4301	0Cr18Ni9	≤0.08	18.00-20.00	8.00-10.00	≤2.00	≤0.045	≤0.030	-	≤0.75	-	-	-
304L	1.4307	00Cr19Ni10	≤0.030	18.00-20.00	8.00-10.00	≤2.00	≤0.045	≤0.030	-	≤0.75	-	-	-
304H	1.4948	0Cr18Ni9	0.04~0.10	18.00-20.00	8.00-10.00	≤2.00	≤0.045	≤0.030	-	≤0.75	-	-	-
309S	1.4833	0Cr23Ni13	≤0.08	22.00-24.00	12.00-15.00	≤2.00	≤0.045	≤0.030	-	≤0.75	-	-	-
309	1.4828	0Cr23Ni13	0.04~0.10	22.00-24.00	12.00-15.00	≤2.00	≤0.045	≤0.030	-	≤0.75	-	-	-
310S	1.4842	0Cr25Ni20	≤0.08	24.00-26.00	19.00-22.00	≤2.00	≤0.045	≤0.030	-	≤1.5	-	-	-
310H	1.4821	0Cr25Ni20	0.04~0.10	24.00-26.00	19.00-22.00	≤2.00	≤0.045	≤0.030	-	≤1.5	-	-	-
314	1.4841	0Cr25Ni20Si	≤0.25	23.00-26.00	19.00-22.00	≤2.00	≤0.045	≤0.030	-	1.5-3.0	-	-	-
316	1.4401	0Cr17Ni12Mo2	≤0.08	16.00-18.50	10.00-14.00	≤2.00	≤0.045	≤0.030	2.00-3.00	≤0.75	-	-	-
316L	1.4404	00Cr17Ni14Mo2	≤0.030	16.00-18.00	10.00-14.00	≤2.00	≤0.045	≤0.030	2.00-3.00	≤0.75	-	-	-
316H	1.4436	0Cr17Ni12Mo2N	0.04~0.10	16.00-18.00	10.00-14.00	≤2.00	≤0.045	≤0.030	2.00-3.00	≤0.75	-	0.10-0.22	-
316Ti	1.4571	0Cr17Ni12Mo2Ti	≤0.08	16.00-18.50	10.00-14.00	≤2.00	≤0.045	≤0.030	2.00-3.00	≤0.75	-	-	Ti5(C+N)~0.7
317	1.4445	0Cr19Ni13Mo3	≤0.08	18.00-20.00	11.00-15.00	≤2.00	≤0.045	≤0.030	3.00-4.00	≤0.75	-	0.1	-
317L	1.4438	00Cr19Ni13Mo3	≤0.03	18.00-20.00	11.00-15.00	≤2.00	≤0.045	≤0.030	3.00-4.00	≤0.75	-	0.1	-
321	1.4541	0Cr18Ni10Ti	≤0.08	17.00-19.00	9.00-12.00	≤2.00	≤0.045	≤0.030	-	≤0.75	-	0.1	Ti5(C+N)~0.7
321H	1.4940	0Cr18Ni10Ti	0.04~0.10	17.00-19.00	9.00-12.00	≤2.00	≤0.045	≤0.030	-	≤0.75	-	0.1	Ti4(C+N)~0.7
329	1.4480	0Cr26Ni5Mo2	≤0.08	23.00-28.00	2.00-5.00	≤1.00	≤0.040	≤0.030	1.00-2.00	≤0.75	-	-	-
329J1	1.4480	0Cr26Ni5Mo2	≤0.08	23.00-28.00	2.00-5.00	≤1.00	≤0.045	≤0.030	1.00-2.00	≤0.75	-	-	-
330	1.4864	N08330	≤0.15	14.00-17.00	33.00-37.00	≤2.00	≤0.045	≤0.040	1.00-2.00	≤1.5	-	-	-
347	1.4550	0Cr18Ni11Nb	≤0.08	17.00-19.00	9.00-13.00	≤2.00	≤0.045	≤0.030	-	≤0.75	-	-	Nb≥10*C%-1.0
347H	1.4912	0Cr18Ni11Nb	0.04~0.10	17.00-19.00	9.00-13.00	≤2.00	≤0.045	≤0.030	-	≤0.75	-	-	Nb≥8*C%-1.0
409L	1.4720	S40900	≤0.03	10.50-11.70	0.5	≤1.00	≤0.040	≤0.020	-	≤1.00	-	0.03	Ti6(C+N)-0.5 Nb0.17
430	1.4016	S43000	≤0.12	16.00-18.00	0.75	≤1.00	≤0.040	≤0.030	-	≤1.00	-	-	-
436	1.4513	S43600	≤0.025	16.00-19.00	-	≤1.00	≤0.040	≤0.030	0.75-1.0	≤1.00		≤0.025	Nb+Ti:8(C+N)~0.80
439	1.4510	S43035	≤0.030	17.50-18.50	-	≤1.00	≤0.040	≤0.015	-	≤1.00	-	≤0.030	Ti+Nb:0.2+4C~0.75
441	1.4509	S44100	≤0.030	17.50-18.50	-	≤1.00	≤0.040	≤0.015	-	≤1.00	-	≤0.030	Ti:0.1-0.6 Nb:3C+0.3~1.0
442	1.4741	S44200	≤0.025	18.0-23.0	-	≤1.00	≤0.040	≤0.035	-	≤1.00	-
443		S44300	≤0.025	19.5-22.0	-	≤1.00	≤0.035	≤0.015	-	≤1.00	-	≤0.025	Nb+Ti:0.2+4(C+N)~0.75
444	1.4521	S44400	≤0.025	17.00-20.00	-	≤1.00	≤0.040	≤0.030	1.75-2.5	≤1.00		≤0.035	Ti+Nb:0.2+4(C+N)~0.8
446	1.4749	S44600	≤0.2	23.0-27.0	0.75	≤1.50	≤0.040	≤0.030	-	≤1.00		0.25
410	1.4006	1Cr13	0.08~0.15	11.50-13.50	-	≤1.00	≤0.040	≤0.030	-	≤1.00	-	-	-
420	1.4031	2Cr13	≥0.15	12.00-14.00	-	≤1.00	≤0.040	≤0.030	-	≤1.00	-	-	-
420J2	1.4028	3Cr13	0.26-0.35	12.00-14.00	-	≤1.00	≤0.040	≤0.030	-	≤1.00	-	-	-
S42040	1.4034	4Cr13	0.36-0.45	12.00-14.00	-	≤1.00	≤0.040	≤0.030	-	≤1.00	-	-	-
431	1.4057	1Cr17Ni2	≤0.2	15.00-17.00	1.25-2.50	≤1.00	≤0.040	≤0.030	-	≤1.00	-	-	-
440A	1.4040	7Cr17	0.60-0.75	16.00-18.00	-	≤1.00	≤0.040	≤0.030	0.75	≤1.00	-	-	-
440B	1.4041	8Cr17	0.75-0.95	16.00-18.00	-	≤1.00	≤0.040	≤0.030	0.75	≤1.00	-	-	-
440C	1.4023	11Cr17	0.95-1.20	16.00-18.00	-	≤1.00	≤0.040	≤0.030	0.75	≤1.00	-	-	-
17-4PH	1.4542	630	≤0.07	15.50-17.50	3.00-5.00	≤1.00	≤0.040	≤0.030	-	≤1.00	3.00-5.00	-	Nb+Ta:0.15-0.45
17-7PH	1.4568	631	≤0.09	16.00-18.00	6.50-7.50	≤1.00	≤0.040	≤0.030	-	≤1.00	-	-	Al 0.75-1.50
15-5PH	1.4545	S15500	≤0.09	14.00-15.50	3.50-5.50	≤1.00	≤0.040	≤0.030	2.00-3.00	≤1.00	2.50-4.50	-
416	1.4005	Y1Cr13	≤0.15	12.00-14.00	-	≤1.25	≤0.06	≥0.15	-	≤1.00	-	-	-
420F	1.4029	Y3Cr13	0.3-0.40	12.00-14.00	0.5	≤1.25	≤0.06	≥0.15	-	≤1.00	0.6	-	-
430F	1.4019,1.4104	Y1Cr17	≤0.12	16.00-18.00	-	≤1.25	≤0.06	≥0.15	-	≤1.00	-	-	-
440F	1.4025	Y11Cr17	0.95-1.20	16.00-18.00	-	≤1.25	≤0.06	≥0.15	-	≤1.00	-	-	-
303	1.4305	S30317	≤0.15	17.00-19.00	8.00-10.00	≤2.00	≤0.20	≥0.15	-	≤1.00	-	-	-
